Replaces Part Number: 951-15236 751-15236
Replaces Huayi 170SD 175SC MTD Craftsman SB410 24″ 31AS6BEE793 snowblower part number 951-15236
Replaces Troy-Bilt 31BS6BN2711 Storm 2410 Snow blower; Replaces MTD 31AS6BEE799 (247.881732)(2015) Snowblower
Replaces Troy-Bilt 270-WU 270-WUA 670-WU 670-WUA 670-WUB 208cc Engine
Package includes: 1 x Carburetor, 2 x Fuel Hose,2 x Fuel Filter, 1 x Primer Bulb, 1 x Shut Off Valve Replaces MTD 951-15236 751-15236
Center to center mounting hole distance: 40mm/1.57″
Central bore diameter: 19mm/0.74″
Replaces Huayi 170SD 175SC
Replaces Cub Cadet 670-WU 208CC Engine
Center to Center Mounting Hole Distance: 40mm/1.57″
Primer Port Nozzle O.D.: 5mm/0.2″
Fuel Inlet Nozzle O.D.: 9mm/0.35″
Replaces MTD 31AS6BEE799 (247.881732)(2015) Snowblower 270-WU Misc Tool 670-WU Misc Tool 670-WUA Misc Tool
Replaces Troy-Bilt 270-WU 280cc Engine 670-WU 208cc Engine 670-WU Engine 670-WUA 208cc Engine 270 WUA 208cc Engine 670-WUB 208cc Engine
PC210075 Carburetor
PC210098 Carburetor
PC164236 Carburetor (model in current listing)
Replaces Troy Bilt MTD Cub Cadet Part Number
951-10974 951-10974A 951-12705
951-10956 951-10956A 751-10956 751-10956A 751-14018 951-14018 751-12612 951-12612
951-15236 751-15236
Choke Direction
Auto choke with teethed gear/friction stops.
Manual choke with teethed gear/friction stops. Turning clock-wise to the fuel nozzle, and stops at a right angle to the fuel nozzle when fully opened.
Choke with teethed gear/friction stops.
Replaces Part Number
Huayi 165S 165SA 520-862
Huayi 161SA 161S MTD, Cub Cadet Troy Bilt 161-JW 161-JWA snow engine
Huayi 170SD 175SC
Compatible Models
Cub Cadet 165-SUB 265-SU 365-SUB MTD 31A-32AD700 31A-32AD706 31A-32AD729 31A-32AD752 31A-32AD762 31A-62EE729 Troy Bilt 31AM62N2711 (600 series) 31AM2N1B795 (2008)
Cub Cadet Models 31A-2M1A700 (2008) 31A-2M1A700 (2009) 31A-2M1A700 (2010) 31A-2M1A706 (2009) 31A-2M1A706 (2010) 31A-2M1A729 (2008)
Cub Cadet 670-WU 208CC Engine MTD 31AS6BEE799 (247.881732)(2015) Snowblower 270-WU Misc Tool 670-WU Misc Tool
Center to Center Mounting Hole Distance: 40mm/1.57″ Central Bore Diameter: 19mm/0.74″
