Replaces Craftsman 536.886120 536.886122 536.881501 536.885473 536.909400 Snow Blower
Replaces Craftsman 536.886440 536.884822 536.886540 536.885400 Snow Blower
Replaces Craftsman 536.884800 536.88612 536.886141 536.88547 Snow Blower
Package includes: 1 x carburetor, 1 x Gasket, 1 x primer hose, 1 x fuel hose,1 x fuel filter, 2 x small clamps for primer hose, 2 x large clamps for fuel hose, 1 x shut-off valve, 1 x primer bulb Works with5hp 6hp 7hp engine
Bore diameter on the front: 20.52mm/0.8″
Center to center mounting hole distance on the front: 44mm/1.73″
Fuel nozzle O.D.: 7.9mm/0.31″
Replaces part number 632107 632107A 640084 640084A 640084B 640105 640299 640299A 640299B
ReplacesHS50 HSK40 HSK50 HSSK40 HSSK50 HSSK55 LH195SA LH195SP OHSK110 OHSK120 OHSK125
Bore diameter on the back: 22.17mm/0.87″
Center to center mounting hole distance on the back: 34mm/1.34″
Primer port nozzle O.D.: 5mm/0.2″
Replaces 520-902
Replaces Toro 38035 38052 38054 38052C 38035C 38056
This carburetor is pre-adjusted for use. No further adjustments are required before installation.
Please pay special attention to the choke part of your carb. If the choke setup of your current carburetor appears to be different from the one we listed in current listing, you may be looking for other similar models. Check out below chart for comparison and order accordingly.
PC210801 Carburetor (model in current listing)
PC210052 Carburetor
PC210086 Carburetor
PC144371 Carburetor
PC144615 Carburetor
Choke Direction
Auto choke. Turning clock-wise towards the same side of the fuel nozzle with teethed gear/friction stops.
Auto choke with teethed gear/friction stops. Turning clock-wise away from the fuel nozzle, and stops at a right angle to the fuel nozzle when fully opened.
Manual handle choke with teethed gear/friction stops. Turning clock-wise away from the fuel nozzle, and stops at a right angle to the fuel nozzle when fully opened.
Vertical standup choke with teethed gear/friction stops.
Bent/angled choke handle located to the other side of the fuel nozzle. Turning counter-clockwise towards the fuel nozzle, and stops at a right angle to the fuel nozzle when fully opened.
ReplacesPart Number
632107 632107A 640084 640084A 640084B 640105 640299 640299A 640299B
640052 640054 640058 640058A 640349
632552 632557 632557A 632560 632560A 632641 640086 640086A 640092A 640092 640311 640098A
632371 632371A
631070 631070A 631074 631921 631245 631820 632615 632208 632589 632284 640129
Replaces Part Number
520-902; TORO 38035 38052 38054 38052C 38035C 38056.
MFG 5313 5002 5036; OREGON 50-659; 520-926.
520-940 056-304, Rotary 13147, MFG 1135 1471 1483.
Compatible Models
HS50 HSK40 HSK50 HSSK40 HSSK50 HSSK55 LH195SA LH195SP OHSK110 OHSK120 OHSK125
LH318SA LH358SA TRX24 TRX26 TRX27 TRX32 TRS22 TRS24 TRS26 TRS27 TRS32
HSK600 HSK635 TH098SA TC-632557 TC-640092 TC-640092A
H50 HSK50 H60 HSK60 H70 HSK70 Snow Thrower Blowers
H25 H30 H35 H40 H50 engine
Adjustable Screws

Choke with teethed gear/friction stops

Primer Port
