Moto Tassinari V3141-682A-3 VForce3 Reed Valve

Applications:
Select SX VIPER/ SX VIPER ER/SRX & Triple V-MAX 600/700 models

The VForce reed valve system by Moto Tassinari has been the reed valve system of choice by anyone serious about two-stroke engine performance for the last 10+ years. The simple premise of the VForce3 reed valve system is to increase engine power and throttle response by increasing the efficiency over a conventional reed valve design.

Fitment:
.table-Moto-Tassinari { border-collapse: collapse; border: 1px solid #000000;} .table-Moto-Tassinari td { border-collapse: collapse; border: 1px solid #000000; padding: 5px 15px 5px 15px; } .table-Moto-Tassinari th { background-color: #BEBEBE; border: 1px solid #000000; padding: 5px 15px 5px 15px; color: #000000; } .table-Moto-Tassinari tr:nth-child(even) { background-color: #E0E0E0; }

Year
Make
Model

1997-2004
Yamaha
Mountain Max 700

2002-2003
Yamaha
SX Viper

2002-2004
Yamaha
SX Viper ER

2003-2004
Yamaha
SX Viper Mountain

2004
Yamaha
SX Viper S

The unique design of the VForce reed valve system features double the reed tip surface over a conventional reed valve design. This has two major benefits: 1) The reed petals only travel half the distance as a conventional reed valve design to get the same airflow. 2) Because the reed petals only need to travel half the distance of that on a conventional reed valve design, there is a greater chance of them being fully opened as well as a better chance of sealing when they are “closed”. A reed petal never truly “closes” in a classic sense, as it is always in movement. Consider this, an engine operating at 8,000 RPM results in a reed petal opening and closing 133 times in one second. This fact, sheds light on another VForce advantage. Since the petals are only traveling half the distance, they generally last longer as they receive less wear than the reed petals on a conventional reed valve design.

VFORCE3 FEATURES

Double the reed tip surface over a conventional reed valve design

Increased bottom end, stronger mid-range and longer top-end

Greater efficiency due to reduced reed petal travel

More airflow means more horsepower

Reduced reed petal wear

Screw free design eliminates risk of screws going through motor

Screw free design enables super quick reed petal changes

Brand: Moto Tassinari
Part Number: V3141-682A-3
