Specifications

Degree of Carbide
60 Degree

Diameter
1/2 in.

Diameter
3/8 in.

Length – Carbide
6 in.

Mfg #:
CAP-S2198-60

Part #:
031655

Stud Count
4

Type
Carbide

Units
Pair

Weight
2.56 lbs

Alternate/OEM Part Number(s):

CAPS219860 Stud Boy Shaper 6 in. Bars For C&A Pro and Curve Ind. XS/XSM Skis Only – CAP-S2198-60

WEAR RODS WILL FIT AFTERMARKET SKIS ONLY – Your ski will be marked on top as Sly Dog, C&A or Curve
The sports first major breakthrough in wear bar technology since the 1950s–these will change the face of control carbide wear bars forever
New design is a unique corner-carving hourglass shape – gives better control at speed with no increased steering effort
Turning radius is an average of 1 to 2 feet tighter in soft snow conditions
Zinc-plated for corrosion resistance
Wear rate for the life of the shaper bar is nearly equal to current round and square wear bar types
Designed and tested by USI
SHAPER 6 in. of 60 degrees cutting carbide
Two 1 1/2 in. carbide wear pads
NOTE: Fits the following C&Amp;A Skis:
Advantage ADX, Advantage X, Mountain, Razor RZ, Race, Trail, Pro Ultra XT, Extreme XT, Sport II Advantage, Ultra Pro XT 5 in. skis and Sly Dog
Dimensions:
Length/Diameter: 16-1/2 in./1/2 in.
Stud Diameter/Length: 3/8 in./1-7/8 in.
Number of Studs: 4
Stud Center Mounting Distance From:
Front to 1st: 1 in.
1st to 2nd: 4 in.
2nd to 3rd: 6-5/8 in.
3rd to 4th: 4-1/2 in.
4th to End: 3/4 in.
